Silkscreen Machine

เครื่องพิมพ์กรีน

KY-600 FH

  • Table size 50×70 cm. (19.6″x27.5″)
  • Max. print size 40×57 cm. (15.7″x22.4″)
  • Max. screen frame size 70×95 cm. (27.5″x37.4″)
  • Screen frame thickness 20~30 mm.
  • Substrate thickness 0~80 mm.
  • Printing speed 500~800 (p/h)
  • Squeegee/coater speed 0~820 (mm/sec.)
  • Squeegee/coater angle adj. 22±15℃
  • Table X/Y adjustment ±10 mm.
  • Table height from ground 870+25 mm.
  • Power source 1.5kw
  • Air Pressure 6~8 kgs/cm2
  • ขนาดเครื่อง (ก.xย.xส.) 128x100x170 cm.
  • น้ำหนัก 320 กิโลกรัม

ALPHA-LINE Printing

  • Machines Size (S / L / XL)
  • 8-20 stations Max.
  • Printsize 530 x 700 mm
  • ALPHA-LINE-S 530 x 500 mm
  • ALPHA-LINE-XL 700 x 1.000 mm
  • Aluminium Sandwich-pallets
  • AUTO-flash-cures with Pyrometer

  • CTS-System for all emulsions

  • Highest print precision +/-0,025 mm allover

  • Wireless squeegee-stroke-length adjustment

BASIC-LINE Printing

  • Machines Size (S / L)
  • 8 – 20 stations Max.
  • Printsize 530 x 500 mm (S)
  • BASIC-LINE blue-L: 530 x 700 mm
  • Aluminium Sandwich pallets
  • Print size 500 x 500 mm / L-500 x 700 mm
  • From/von 6 – 20 stations
  • Squeegee-movement stepless
  • Highest accuracy +/- 0,025 mm
  • Warranty for high class prints

  • Wireless/one hand adjustable

  • Aluminium Sandwich-pallets

S-LINE Printing

  • Machines Size (S)
  • 8 stations Max.
  • Printsize 400 x 400 mm
  • 10 – 12 stations max. Printsize 400 x 450 mm
  • Aluminium-Sandwich-Pallets
  • Pallet-drive: frequency controlled AC-Servo-Gear-Drive
  • 10“ Colour-SMART-touch-screen + Servo-Index-drive + 4 Cylinder POWER-Chopper squeegee + servo squeegee drive
  • Large printsize 400 x 400 mm = smallest carousel-diameter in this class – only 283 cm ø
  • For highest print quality +/- 0,025 mm print-precision + electronic off-contact (5 steps)
  • Repeatable print/flood-squeegee speed-adjustment to adjust on the touch-screen

XS-LINE Printing

  • 8 stations, 5 colors + 1 flash
  • Variable & compact, only 2,20m diameter
  • Print area max. 300 x 210 mm
  • Pallet-drive: frequency controlled AC-Servo-Gear-Drive
  • Swivelling control panel arm with 4” SMART-touch-screen-display
  • Microprocessor with diagnostic-program
  • 8 pces. alu-sandwich pallets 400 x 320 mm with neck
  • 5 pces. print squeegees 310 mm 65°Shore
  • 5 pces. alu-flood-bars 310 mm
  • 1 pce. SPOT-Flash 300 x 210 mm
  • electric: 3x400V V, PEN, 2,5 kW
  • Compressed air: 8 bar, approx. 120-180 ltr./h
  • Machine-diameter: 220 cm / 86”
  • Screen-measurement: 560 x 420 mm ,Profil: 25x 25 mm

OXL-LINE Printing

  • 16-44 stations Max.
  • Printsize 700×900 mm
  • Alu sandwich pallets
  • Print-area 700 x 1.100 mm/28“ x 43“ up to 38 stations
  • AC Servo-pallet-drive AC-Servo-squeegee-drive Touch-screen
  • Control-panels on each printhead individual off-contact
  • Tool-free squeegee-stroke lenght setting independent print/flood speed control on each printhead
  • AC-Service-drive
  • 4-Cylinder POWER-Squeegee-System
  • Print/Floodbars with mechanical way-adjustment for precise height-levelling
  • Individual tool-free squeegee-stroke length setting, speed, height and angle
  • Control-touch pads on each printhead
